882-I

BBE | 882-I
Sonic Maximizer

The 882i is a dual-mono Sonic Maximizer that features our fourth generation processing engine and perfectly suited for any studio, PA system, guitar/bass rig or any application that requires balanced connectivity.

• +4dBu balanced line (1/4" tip-ring-sleeve and XLR inputs and outputs)
• +23dBu headroom
• Active balanced outputs
• Hardwire bypass
• Bypass switch for comparison of processed to unprocessed signal

Specifiche Tecniche:

• Frequency response: Process Mode: Program controlled / Bypass Mode: 10Hz to 50kHz, +/- 0.5dBu, 0dBu input
• Signal to Noise Ratio: 115dB Process IN
• THD: Process mode: less than 0.025% 20-20kHz / Bypass mode: less than 0.002% 20-20kHz
• Maximum Output: +23dBu (may vary due to control settings)
• Input Impedance: 14.7K Ohms, balanced 1/4" stereo phone jack or XLR jack. Pin #2 is the hot or "+" signal.
• Output Impedance: 600 Ohms, balanced 1/4" stereo phone jack or XLR jack. Pin #2 is the hot or "+" signal.
• Sensitivity: -45dBu for maximum process
• Maximum Process: +12dBu boost at 5kHz, 0dBu input
• Lo Contour: +12dBu adjustment at 50Hz, 0dBu input
